HiLetgo 2.2" ILI9225 SPI Serial Port 176x220 TFT LCD Module with SD Socket Support 51/ARM/Arduino

It looks great when I touch the cable from the screen to the board. Easy to setup and get library for. I am requesting replacement so hopefully the second comes in without problems. The failure rate on small screens like this is insane... This is the third type I am trying. This one I am just hoping a replacement fixes the issue.I tried it again later and discovered the top level README info has the wrong pinouts... find them in the example code and it works great on both Uno and Nano.SD card works well too!

It is a nice display. Worked as announced as an arduino hat with software SPI and analog pins. Was not able to use it with hardware SPI on ESP32 but did work with software SPI plus some extra pins. With Duemilanove it work with both hardware and software SPI (plus needed extra pins). The libraries used were the standard TFT_22_ILI9225 ones installed from standard arduino IDE library manager. The board seems to need more pins than the standard SPI MISO, MOSI, SCLK and CS. Giving only 3 stars as it just not only need SPI signals but requires additional RST and RS

I hooked this up to an Arduino Nano clone and it works very well! Both the display and the SD card reader. The SD card reader took me a bit to figure out, but going to lcdwiki dot com and scroll down to SKU:MAR2201 there's a wealth of information!

Haven't had this display 2 months barely used and its getting stripes in one side of it that are getting progressively worse Lasted just past the return policy time. This is the second item ive had issues with from HILETGO so im going to let go and not buy anymore of their items .

Overall good board quality and works as advertised. One thing to note since it is LCD the contrast/brightness isn't great for outdoor use (using as a battery monitor for my esk8) that said for a 2.2" display it looks pretty nice.

More than what expected but at the same time, SD was not wired. Had to dig for correct wiring.

Nice display, used with "GitHub - Nkawu/TFT_22_ILI9225: Arduino library for 2.2" TFT display"

Plugs directly into the analog ports on an Arduino Uno! No complex wiring needed! It was hard to find a library to get it to work, but this Henning Karlsen's UTFT library at http://www.henningkarlsen.com/electronics/library.php?id=52 woked perfectly once I set it up.
